AC Lite

The Ubiquiti UniFi AC Lite (UAP-AC-LITE) is a compact, high-performance 802.11ac Wi-Fi access point designed for cost-effective deployment in homes and small-to-medium businesses. Featuring a sleek, low-profile industrial design, it delivers simultaneous dual-band 2×2 MIMO connectivity with aggregate speeds of up to 1167 Mbps (867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz). It integrates seamlessly into the Ubiquiti ecosystem, allowing for centralized configuration and monitoring via the UniFi Network Controller, and supports Power over Ethernet (PoE) for flexible installation without the need for a dedicated power outlet near the device.
Specifications
| Access Points | |
| General | |
| Brand | Ubiquiti |
| Product Line | Unifi |
| SKU | UAP-AC-Lite |
| MSRP | $89 |
| WiFi Generation | AC Wave 1 |
| Class | AC1200 |
| 2.4 GHz Radio | |
| Standard | WiFi 4 |
| MIMO / Width | 2x2 / 40MHz |
| TX Power | 20 dBm |
| Antenna Gain | 3 dBi |
| Max Data Rate | 300 Mbps |
| 5 GHz Radio | |
| Standard | WiFi 5 |
| MIMO / Width | 2x2 / 80 MHz |
| TX Power | 20 dBm |
| Antenna Gain | 3 dBi |
| Max Data Rate | 867 Mbps |
| 6 GHz Radio | |
| Capabilities | |
| Spatial Streams | 4 |
| Claimed Coverage | 1,250 ft² |
| Claimed Max Clients | 250+ |
| Max BSSID | 8 per radio |
| Physical | |
| Chipset | Qualcomm QCA9560 |
| Ports | (1) 1 Gbps |
| PoE In | PoE 24V / 48V |
| Max Consumption | 6.5W |
| Mounting Location | Ceiling / Wall |
| Environment | Indoor |
| Dimensions Imperial | 6.3 x 1.2" |
| Dimensions Metric | 160 x 31 mm |
