AC Lite

The Ubiquiti UniFi AC Lite (UAP-AC-LITE) is a compact, high-performance 802.11ac Wi-Fi access point designed for cost-effective deployment in homes and small-to-medium businesses. Featuring a sleek, low-profile industrial design, it delivers simultaneous dual-band 2×2 MIMO connectivity with aggregate speeds of up to 1167 Mbps (867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz). It integrates seamlessly into the Ubiquiti ecosystem, allowing for centralized configuration and monitoring via the UniFi Network Controller, and supports Power over Ethernet (PoE) for flexible installation without the need for a dedicated power outlet near the device.

Compare

Specifications

Access Points
General
Brand Ubiquiti
Product Line Unifi
SKU UAP-AC-Lite
MSRP $89
WiFi Generation AC Wave 1
Class AC1200
2.4 GHz Radio
Standard WiFi 4
MIMO / Width 2x2 / 40MHz
TX Power 20 dBm
Antenna Gain 3 dBi
Max Data Rate 300 Mbps
5 GHz Radio
Standard WiFi 5
MIMO / Width 2x2 / 80 MHz
TX Power 20 dBm
Antenna Gain 3 dBi
Max Data Rate 867 Mbps
6 GHz Radio
Capabilities
Spatial Streams 4
Claimed Coverage 1,250 ft²
Claimed Max Clients 250+
Max BSSID 8 per radio
Physical
Chipset Qualcomm QCA9560
Ports (1) 1 Gbps
PoE In PoE 24V / 48V
Max Consumption 6.5W
Mounting Location Ceiling / Wall
Environment Indoor
Dimensions Imperial 6.3 x 1.2"
Dimensions Metric 160 x 31 mm
